general characteristics

Type : Bulk container with open roof
Material : Robust Corten steel, designed to withstand extreme conditions and heavy loads
Standard : ISO and IICL (optimum quality and durability)
Structure :
Reinforced corrugated walls for extra strength
Rigid or canvas opening roof, facilitating the loading of bulk materials
Internal lashings for securing goods
Floor : Plywood or reinforced steel, depending on the model
Doors :
Standard double rear door for unloading
Full or partial roof opening, allowing top loading
Waterproofing : 100% airtight, protected against moisture and water infiltration

External dimensions

Length : 6.06 m (20'0")
Width : 2.44 m (8'0")
Height : 2.59 m (8'6")

Internal dimensions

Length : 5.90 m (19'4")
Width  : 2.35 m (7'9")
Height : 2.39 m (7'10")

Roof opening

Opening width : Approx.  2.20 m (7'2")
Opening time : approx. 5.80 m (19'0")

Capacity and maximum load

Internal volume : approx. 32.5 m³
Empty weight : 2,500 – 2,700 kg (depending on model)
Maximum payload : 28,000 kg

Uses and applications

Bulk transport : Ideal for grain, ore, pellets, sand, coal and other materials that require top loading
Temporary storage : Used to safely store raw materials and industrial products
Industry and logistics : Suitable for the agricultural, mining, construction and recycling sectors
Sea and land transport : Suitable for ships, trains and trucks, allowing loading via cranes and hoppers

Advantages

Full or partial roof opening : Simplified loading of bulk products
ISO & IICL standard : High quality, designed for a long service life and intensive  use
Enhanced security: fastening rings and secure locking system
Waterproofing and resistance: Protection against moisture, corrosion and bad weather
Easy handling: Can be moved by crane, forklift or pallet truck

Conclusion

The 20-foot open-top shipping container – Bulk is a high-quality and safe solution for the transport and storage of bulk goods. Thanks to its openable roof, robustness and large capacity, it is a strategic investment for companies in agriculture, mining, industry and logistics that require fast and efficient handling of bulk materials.
