General characteristics

Type : High Cube dry shipping container with side door
Standard : ISO and IICL (maximum quality and durability)
Material : robust Corten steel, designed to carry heavy loads and withstand extreme conditions
Structure :
High cube height (+30 cm more than a standard container) for a larger internal volume
Reinforced corrugated walls for greater strength
Internal and external fixing rings to secure cargo
Floor : Non-slip marine grade plywood, designed to carry heavy loads
Doors :
Standard double rear door with secure locking system
Large side door on one side, allowing easy access to goods along the entire length of the container
Robust locking system with secure locking bars
Waterproofing : 100% airtight, protected against moisture and corrosion

External dimensions

Length : 12.19 m (40'0")
Width : 2.44 m (8'0")
Height : 2.89 m  (9'6")

Internal dimensions

Length: 12.00 m (39'4")
Width: 2.35 m (7'9")
Height: 2.69 m (8'10")

Side opening

Total opening width: approx. 11.80 m (38'8")
Opening height: Approx. 2.60 m (8'6")

Capacity and maximum load

Internal volume: approx. 76.4 m³
Empty weight: 4,000 – 4,500 kg (depending on model)
Maximum payload: 28,000 kg

Uses and applications

Transport of bulky goods requiring easy lateral access
Optimized storage, allowing quick access to goods without having to unload everything
Logistics and distribution, ensuring better organization and efficient stock management
Modular solutions, which can be converted into a mobile warehouse,  office, showroom or workshop

Advantages

Full side opening, making loading and unloading easier
High Cube height (+30 cm), offering more interior space
IICL and ISO standard, guaranteeing superior quality and durability
Enhanced security, with a robust locking system
Waterproofing and protection against moisture, corrosion and extreme weather conditions
Easy to handle, compatible with crane, forklift and pallet truck

Conclusion

The 40ft High Cube Shipping Container with Side Door (HCSD) is a highly functional solution for professionals in transport, logistics and storage. Its double access (rear and side door), robustness and optimized interior volume make it a strategic choice for companies that require fast and efficient handling of their goods.
